Neural boundary shape functions in physics-informed neural networks for discontinuous and high-frequency problems

doi:10.1007/s10483-026-3350-8

摘要/Abstract

Abstract:

Physics-informed neural networks (PINNs) have been shown as powerful tools for solving partial differential equations (PDEs) by embedding physical laws into the network training. Despite their remarkable results, complicated problems such as irregular boundary conditions (BCs) and discontinuous or high-frequency behaviors remain persistent challenges for PINNs. For these reasons, we propose a novel two-phase framework, where a neural network is first trained to represent shape functions that can capture the irregularity of BCs in the first phase, and then these neural network-based shape functions are used to construct boundary shape functions (BSFs) that exactly satisfy both essential and natural BCs in PINNs in the second phase. This scheme is integrated into both the strong-form and energy PINN approaches, thereby improving the quality of solution prediction in the cases of irregular BCs. In addition, this study examines the benefits and limitations of these approaches in handling discontinuous and high-frequency problems. Overall, our method offers a unified and flexible solution framework that addresses key limitations of existing PINN methods with higher accuracy and stability for general PDE problems in solid mechanics.

Key words: physics-informed neural network (PINN), boundary shape function (BSF), strong-form approach, energy approach, discontinuity, high-frequency problem

中图分类号:

. [J]. Applied Mathematics and Mechanics (English Edition), 2026, 47(2): 423-442.

P. T. NGUYEN, K. A. LUONG, J. H. LEE. Neural boundary shape functions in physics-informed neural networks for discontinuous and high-frequency problems[J]. Applied Mathematics and Mechanics (English Edition), 2026, 47(2): 423-442.

图/表 27

Activation function	Method	Optimizer
Activation function	Method	Adam	L-BFGS	Adagrad	Adam+L-BFGS
$Tanh$	Present-SF	$2.4 × 10 − 3$	$6.3 × 10 − 6$	$2.2 × 10 − 2$	$2.5 × 10 − 6$
$Tanh$	Present-En	$2.7 × 10 − 4$	$2.3 × 10 − 4$	$1.3 × 10 − 3$	$2.3 × 10 − 4$
$Sine$	Present-SF	$2.9 × 10 − 4$	$2.7 × 10 − 6$	$5.1 × 10 − 4$	$3.9 × 10 − 6$
$Sine$	Present-En	$2.8 × 10 − 4$	$2.4 × 10 − 4$	$2.8 × 10 − 4$	$2.4 × 10 − 4$
$Sigmoid$	Present-SF	$2.6 × 10 − 3$	$7.5 × 10 − 5$	$2.5 × 10 − 1$	$2.2 × 10 − 5$
$Sigmoid$	Present-En	$2.2 × 10 − 3$	$2.2 × 10 − 4$	$4.5 × 10 − 3$	$2.4 × 10 − 4$
$Relu$	Present-SF	$1.5 × 100$	$1.6 × 100$	$1.7 × 100$	$1.6 × 100$
$Relu$	Present-En	$> 102$	$> 102$	$> 102$	$> 102$
Note: Adam represents the adaptive moment estimation, L-BFGS represents the limited-memory Broyden-Fletcher-Goldfarb-Shanno algorithm, and Adagrad represents the adaptive gradient algorithm

Method	Two hidden layers			Three hidden layers
Method	30 neurons	40 neurons	50 neurons	30 neurons	40 neurons	50 neurons
Present-SF	$6.5 × 10 − 6$	$7.9 × 10 − 6$	$6.7 × 10 − 6$	$2.5 × 10 − 6$	$8.2 × 10 − 6$	$9.2 × 10 − 6$
Present-En	$2.3 × 10 − 4$	$1.9 × 10 − 4$	$2.3 × 10 − 4$	$2.3 × 10 − 4$	$2.1 × 10 − 4$	$2.1 × 10 − 4$

参考文献 45

[1]	JOHNSON, C. Numerical Solution of Partial Differential Equations by the Finite Element Method, Cambridge University Press, Cambridge (1988)
[2]	ÖZIŞIK, M. N., ORLANDE, H. R., COLAÇO, M. J., and COTTA, R. M. Finite Difference Methods in Heat Transfer, CRC Press, New York (2017)
[3]	HESTHAVEN, J. S., GOTTLIEB, D. I., and GOTTLIEB, S. Spectral Methods for Time-Dependent Problems, Cambridge University Press, Cambridge (2007)
[4]	LEVEQUE, R. J. Finite Difference Methods for Ordinary and Partial Differential Equations: Steady-State and Time-Dependent Problems, Society for Industrial and Applied Mathematics, United States (2007)
[5]	HUGHES, T. J. The Finite Element Method: Linear Static and Dynamic Finite Element Analysis, Dover Publications, Mineola, NY (2003)
[6]	KOPRIVA, D. A. Implementing Spectral Methods for Partial Differential Equations: Algorithms for Scientists and Engineers, Springer Science & Business Media, Berlin (2009)
[7]	POZRIKIDIS, C. Finite and Spectral Element Methods Using Matlab, University of California, San Diego, U. S. A. (2005)
[8]	RAISSI, M., PERDIKARIS, P., and KARNIADAKIS, G. E. Physics-informed neural networks: a deep learning framework for solving forward and inverse problems involving nonlinear partial differential equations. Journal of Computational Physics, 378, 686–707 (2019)
[9]	E, W. and YU, B. The deep ritz method: a deep learning-based numerical algorithm for solving variational problems. Communications in Mathematics and Statistics, 66, 1–12 (2018)
[10]	WU, Z., WANG, H., HE, C., ZHANG, B., XU, T., and CHEN, Q. The application of physics-informed machine learning in multiphysics modeling in chemical engineering. Industrial & Engineering Chemistry Research, 62(44), 18178–18204 (2023)
[11]	CAI, S., WANG, Z., WANG, S., PERDIKARIS, P., and KARNIADAKIS, G. E. Physics-informed neural networks for heat transfer problems. Journal of Heat Transfer, 143(6), 060801 (2021)
[12]	WU, Y., FENG, W., LI, Y., ZHANG, K., and YANG, F. Dual-stage method with PINN for coupled strong-form diffusion and energy-based deformation analysis in lithium-ion batteries. Applied Mathematical Modelling, 143, 115986 (2025)
[13]	BAI, J., LIN, Z., WANG, Y., WEN, J., LIU, Y., RABCZUK, T., GU, Y., and FENG, X. Q. Energy-based physics-informed neural network for frictionless contact problems under large deformation. Computer Methods in Applied Mechanics and Engineering, 437, 117787 (2025)
[14]	HU, Z., SHUKLA, K., KARNIADAKIS, G. E., and KAWAGUCHI, K. Tackling the curse of dimensionality with physics-informed neural networks. Neural Networks, 176, 106369 (2024)
[15]	LE-DUC, T., LEE, S., NGUYEN-XUAN, H., and LEE, J. A hierarchically normalized physics-informed neural network for solving differential equations: application for solid mechanics problems. Engineering Applications of Artificial Intelligence, 133, 108400 (2024)
[16]	BAI, J., LIU, G. R., GUPTA, A., ALZUBAIDI, L., FENG, X. Q., and GU, Y. Physics-informed radial basis network (PIRBN): a local approximating neural network for solving nonlinear partial differential equations. Computer Methods in Applied Mechanics and Engineering, 415, 116290 (2023)
[17]	JAGTAP, A. D., KAWAGUCHI, K., and KARNIADAKIS, G. E. Adaptive activation functions accelerate convergence in deep and physics-informed neural networks. Journal of Computational Physics, 404, 109136 (2020)
[18]	TOSCANO, J. D., OOMMEN, V., VARGHESE, A. J., ZOU, Z., AHMADI DARYAKENARI, N., WU, C., and KARNIADAKIS, G. E. From PINNs to PIKANs: recent advances in physics-informed machine learning. Machine Learning for Computational Science and Engineering, 1(1), 15 (2025)
[19]	RAHAMAN, N., BARATIN, A., ARPIT, D., DRAXLER, F., LIN, M., HAMPRECHT, F. A., BENGIO, Y., and COURVILLE, A. On the spectral bias of neural networks. The 36th International Conference on Machine Learning, 5301–5310 (2019)
[20]	WANG, S., TENG, Y., and PERDIKARIS, P. Understanding and mitigating gradient flow pathologies in physics-informed neural networks. SIAM Journal on Scientific Computing, 43(5), A3055–A3081 (2021)
[21]	SON, H., CHO, S. W., and HWANG, H. J. Enhanced physics-informed neural networks with augmented Lagrangian relaxation method (AL-PINNs). Neurocomputing, 548, 126424 (2023)
[22]	CHEN, Z., LAI, S. K., YANG, Z., NI, Y. Q., YANG, Z., and CHEUNG, K. C. AT-PINN-HC: a refined time-sequential method incorporating hard-constraint strategies for predicting structural behavior under dynamic loads. Computer Methods in Applied Mechanics and Engineering, 436, 117691 (2025)
[23]	LYU, L., WU, K., DU, R., and CHEN, J. Enforcing exact boundary and initial conditions in the deep mixed residual method. CSIAM Transactions on Applied Mathematics, 2, 748–775 (2021)
[24]	LUONG, K. A., LE-DUC, T., and LEE, J. Deep reduced-order least-square method — a parallel neural network structure for solving beam problems. Thin-Walled Structures, 191, 111044 (2023)
[25]	DE RYCK, T. and MISHRA, S. Numerical analysis of physics-informed neural networks and related models in physics-informed machine learning. Acta Numerica, 33, 633–713 (2024)
[26]	HU, Z., SHI, Z., KARNIADAKIS, G. E., and KAWAGUCHI, K. Hutchinson trace estimation for high-dimensional and high-order physics-informed neural networks. Computer Methods in Applied Mechanics and Engineering, 424, 116883 (2024)
[27]	LUONG, K. A., LE-DUC, T., and LEE, J. Automatically imposing boundary conditions for boundary value problems by unified physics-informed neural network. Engineering with Computers, 40(3), 1717–1739 (2024)
[28]	WANG, J., MO, Y. L., IZZUDDIN, B., and KIM, C. W. Exact Dirichlet boundary physics-informed neural network EPINN for solid mechanics. Computer Methods in Applied Mechanics and Engineering, 414, 116184 (2023)
[29]	HU, T., JIN, B., and WANG, F. An iterative deep Ritz method for monotone elliptic problems. Journal of Computational Physics, 527, 113791 (2025)
[30]	DONDL, P., MÜLLER, J., and ZEINHOFER, M. Uniform convergence guarantees for the deep Ritz method for nonlinear problems. Advances in Continuous and Discrete Models, 2022(1), 49 (2022)
[31]	LIU, C. S. A boundary shape function method for analyzing nonlinear composite beams, subjecting to nonlinear boundary moment conditions. Composite Structures, 264, 113636 (2021)
[32]	LIU, C. S., QIU, L., and LIN, J. Simulating thin plate bending problems by a family of two-parameter homogenization functions. Applied Mathematical Modelling, 79, 284–299 (2020)
[33]	CHANG, T. Y., GIE, G. M., HONG, Y., and JUNG, C. Y. Singular layer physics informed neural network method for plane parallel flows. Computers & Mathematics with Applications, 166, 91–105 (2024)
[34]	GIE, G. M., HONG, Y., JUNG, C. Y., and MUNKHJIN, T. Semi-analytic PINN methods for boundary layer problems in a rectangular domain. Journal of Computational and Applied Mathematics, 450, 115989 (2024)
[35]	SUKUMAR, N. and SRIVASTAVA, A. Exact imposition of boundary conditions with distance functions in physics-informed deep neural networks. Computer Methods in Applied Mechanics and Engineering, 389, 114333 (2022)
[36]	REDDY, J. N. Energy Principles and Variational Methods in Applied Mechanics, 3rd ed., John Wiley & Sons, New York (2017)
[37]	SHIN, Y., DARBON, J., and KARNIADAKIS, G. E. On the convergence of physics informed neural networks for linear second-order elliptic and parabolic type PDEs. Communications in Computational Physics, 28, 2042–2074 (2020)
[38]	STEIN, M. Large sample properties of simulations using Latin hypercube sampling. Technometrics, 29(2), 143–151 (1987)
[39]	MISHRA, S. and MOLINARO, R. Estimates on the generalization error of physics-informed neural networks for approximating PDEs. IMA Journal of Numerical Analysis, 43(1), 1–43 (2023)
[40]	DE RYCK, T., MISHRA, S., and MOLINARO, R. wPINNs: weak physics informed neural networks for approximating entropy solutions of hyperbolic conservation laws. SIAM Journal on Numerical Analysis, 62(2), 811–841 (2024)
[41]	CHANG, K., REN, H., and LAI, J. Extended particle weak-form-based neural networks for seismic modeling. IEEE Geoscience and Remote Sensing Letters, 22, 3002605 (2025)
[42]	LIN, P. C. Bending of cantilever rectangular plate with concentrated load. Applied Mathematics and Mechanics (English Edition), 3(2), 281–291 (1982) https://doi.org/10.1007/BF01877662
[43]	MEMA, E., WANG, T., and KNAP, J. Deep Ritz method with Fourier feature mapping: a deep learning approach for solving variational models of microstructure. Journal of Computational Science, 91, 102631 (2025)
[44]	TANCIK, M., SRINIVASAN, P., MILDENHALL, B., FRIDOVICH-KEIL, S., RAGHAVAN, N., SINGHAL, U., RAMAMOORTHI, R., BARRON, J., and NG, R. Fourier features let networks learn high frequency functions in low dimensional domains. Advances in Neural Information Processing Systems, 33, 7537–7547 (2020)
[45]	WATANABE, M. Numerical Methods (Finite Element) for Time-Dependent Partial Differential Equations, M. Sc. dissertation, Utah State University (1982)

Problem	Present method			PINN-SF	PINN-En
Problem	Finding shape functions	Present-SF	Present-En	PINN-SF	PINN-En
Subsection 4.1.1	1.3	8.6	5.1	1.9	1.5
Subsection 4.1.2	16.6	44.7	8.2	9.3	2.2
Subsection 4.2.1	4.7	10.5	5.3	2.6	1.2
Subsection 4.2.2	20.3	–	17.2	–	3.7
Subsection 4.3.1	1.4	9.4	8.3	2.6	1.5
Subsection 4.3.2	16.6	71.2	24.1	17.9	5.4
