当期目录

2021年 第42卷 第6期    刊出日期：2021-06-01

上一期    下一期

论文

Design and dynamic analysis of integrated architecture for vibration energy harvesting including piezoelectric frame and mechanical amplifier

Xiangjian DUAN, Dongxing CAO, Xiaoguang LI, Yongjun SHEN

2021, 42(6):  755-770.  doi:10.1007/s10483-021-2741-8

摘要 ( 1816 )   HTML ( 956)   PDF (2608KB) ( 202 )

参考文献 | 相关文章 | 多维度评价

Vibration energy harvesters (VEHs) can transform ambient vibration energy to electricity and have been widely investigated as promising self-powered devices for wireless sensor networks, wearable sensors, and applications of a micro-electro-mechanical system (MEMS). However, the ambient vibration is always too weak to hinder the high energy conversion efficiency. In this paper, the integrated frame composed of piezoelectric beams and mechanical amplifiers is proposed to improve the energy conversion efficiency of a VEH. First, the initial structures of a piezoelectric frame (PF) and an amplification frame (AF) are designed. The dynamic model is then established to analyze the influence of key structural parameters on the mechanical amplification factor. Finite element simulation is conducted to study the energy harvesting performance, where the stiffness characteristics and power output in the cases of series and parallel load resistance are discussed in detail. Furthermore, piezoelectric beams with variable cross-sections are introduced to optimize and improve the energy harvesting efficiency. Advantages of the PF with the AF are illustrated by comparison with conventional piezoelectric cantilever beams. The results show that the proposed integrated VEH has a good mechanical amplification capability and is more suitable for low-frequency vibration conditions.



Isogeometric nonlocal strain gradient quasi-three-dimensional plate model for thermal postbuckling of porous functionally graded microplates with central cutout with different shapes

Rui SONG, S. SAHMANI, B. SAFAEI

2021, 42(6):  771-786.  doi:10.1007/s10483-021-2725-7

摘要 ( 840 )   HTML ( 751)   PDF (2113KB) ( 157 )

参考文献 | 相关文章 | 多维度评价

This study presents the size-dependent nonlinear thermal postbuckling characteristics of a porous functionally graded material (PFGM) microplate with a central cutout with various shapes using isogeometric numerical technique incorporating nonuniform rational B-splines. To construct the proposed non-classical plate model, the nonlocal strain gradient continuum elasticity is adopted on the basis of a hybrid quasi-three-dimensional (3D) plate theory under through-thickness deformation conditions by only four variables. By taking a refined power-law function into account in conjunction with the Touloukian scheme, the temperature-porosity-dependent material properties are extracted. With the aid of the assembled isogeometric-based finite element formulations, nonlocal strain gradient thermal postbuckling curves are acquired for various boundary conditions as well as geometrical and material parameters. It is portrayed that for both size dependency types, by going deeper in the thermal postbuckling domain, gaps among equilibrium curves associated with various small scale parameter values get lower, which indicates that the pronounce of size effects reduces by going deeper in the thermal postbuckling regime. Moreover, we observe that the central cutout effect on the temperature rise associated with the thermal postbuckling behavior in the presence of the effect of strain gradient size and absence of nonlocality is stronger compared with the case including nonlocality in absence of the strain gradient small scale effect.

Electric potential and energy band in ZnO nanofiber tuned by local mechanical loading

Shuaiqi FAN, Ziguang CHEN

2021, 42(6):  787-804.  doi:10.1007/s10483-021-2736-5

摘要 ( 739 )   HTML ( 575)   PDF (4076KB) ( 117 )

参考文献 | 相关文章 | 多维度评价

Recent success in strain engineering has triggered tremendous interest in its study and potential applications in nanodevice design. In this paper, we establish a coupled piezoelectric/semiconducting model for a wurtzite structure ZnO nanofiber under the local mechanical loading. The energy band structure tuned by the local mechanical loading and local length is calculated via an eight-band k·p method, which includes the coupling of valance and conduction bands. Poisson's effect on the distribution of electric potential inversely depends on the local mechanical loading. Numerical results reveal that both the applied local mechanical loading and the local length exhibit obvious tuning effects on the electric potential and energy band. The band gap at band edges varies linearly with the applied loading. Changing the local length shifts the energy band which is far away from the band edges. This study will be useful in the electronic and optical enhancement of semiconductor devices.

Nonlinear dynamic responses of sandwich functionally graded porous cylindrical shells embedded in elastic media under 1:1 internal resonance

Yunfei LIU, Zhaoye QIN, Fulei CHU

2021, 42(6):  805-818.  doi:10.1007/s10483-021-2740-7

摘要 ( 742 )   HTML ( 508)   PDF (3865KB) ( 116 )

参考文献 | 相关文章 | 多维度评价

In this article, the nonlinear dynamic responses of sandwich functionally graded (FG) porous cylindrical shell embedded in elastic media are investigated. The shell studied here consists of three layers, of which the outer and inner skins are made of solid metal, while the core is FG porous metal foam. Partial differential equations are derived by utilizing the improved Donnell's nonlinear shell theory and Hamilton's principle. Afterwards, the Galerkin method is used to transform the governing equations into nonlinear ordinary differential equations, and an approximate analytical solution is obtained by using the multiple scales method. The effects of various system parameters, specifically, the radial load, core thickness, foam type, foam coefficient, structure damping, and Winkler-Pasternak foundation parameters on nonlinear internal resonance of the sandwich FG porous thin shells are evaluated.

Vibration characteristics of piezoelectric functionally graded carbon nanotube-reinforced composite doubly-curved shells

V. V. THAM, H. Q. TRAN, T. M. TU

2021, 42(6):  819-840.  doi:10.1007/s10483-021-2730-7

摘要 ( 797 )   HTML ( 528)   PDF (1055KB) ( 131 )

参考文献 | 相关文章 | 多维度评价

This paper presents an analytical solution for the free vibration behavior of functionally graded carbon nanotube-reinforced composite (FG-CNTRC) doubly curved shallow shells with integrated piezoelectric layers. Here, the linear distribution of electric potential across the thickness of the piezoelectric layer and five different types of carbon nanotube (CNT) distributions through the thickness direction are considered. Based on the four-variable shear deformation refined shell theory, governing equations are obtained by applying Hamilton's principle. Navier's solution for the shell panels with the simply supported boundary condition at all four edges is derived. Several numerical examples validate the accuracy of the presented solution. New parametric studies regarding the effects of different material properties, shell geometric parameters, and electrical boundary conditions on the free vibration responses of the hybrid panels are investigated and discussed in detail.

A high order boundary scheme to simulate complex moving rigid body under impingement of shock wave

Ziqiang CHENG, Shihao LIU, Yan JIANG, Jianfang LU, Mengping ZHANG, Shuhai ZHANG

2021, 42(6):  841-854.  doi:10.1007/s10483-021-2735-7

摘要 ( 975 )   HTML ( 581)   PDF (1625KB) ( 184 )

参考文献 | 相关文章 | 多维度评价

In the paper, we study a high order numerical boundary scheme for solving the complex moving boundary problem on a fixed Cartesian mesh, and numerically investigate the moving rigid body with the complex boundary under the impingement of an inviscid shock wave. Based on the high order inverse Lax-Wendroff (ILW) procedure developed in the previous work (TAN, S. and SHU, C. W. A high order moving boundary treatment for compressible inviscid flows. Journal of Computational Physics, 230(15), 6023-6036 (2011)), in which the authors only considered the translation of the rigid body, we consider both translation and rotation of the body in this paper. In particular, we reformulate the material derivative on the moving boundary with no-penetration condition, and the newly obtained formula plays a key role in the proposed algorithm. Several numerical examples, including cylinder, elliptic cylinder, and NACA0012 airfoil, are given to indicate the effectiveness and robustness of the present method.

Nonlocal thermoelastic analysis of a functionally graded material microbeam

Wei PENG, Like CHEN, Tianhu HE

2021, 42(6):  855-870.  doi:10.1007/s10483-021-2742-9

摘要 ( 871 )   HTML ( 604)   PDF (428KB) ( 209 )

参考文献 | 相关文章 | 多维度评价

In extreme heat transfer environments, functionally graded materials (FGMs) have aroused great concern due to the excellent thermal shock resistance. With the development of micro-scale devices, the size-dependent effect has become an important issue. However, the classical continuum mechanical model fails on the micro-scale due to the influence of the size-dependent effect. Meanwhile, for thermoelastic behaviors limited to small-scale problems, Fourier's heat conduction law cannot explain the thermal wave effect. In order to capture the size-dependent effect and the thermal wave effect, the nonlocal generalized thermoelastic theory for the formulation of an FGM microbeam is adopted in the present work. For numerical validation, the transient responses for a simply supported FGM microbeam heated by the ramp-type heating are considered. The governing equations are formulated and solved by employing the Laplace transform techniques. In the numerical results, the effects of the ramp-heating time parameter, the nonlocal parameter, and the power-law index on the considered physical quantities are presented and discussed in detail.

Numerical method for simulating rarefaction shocks in the approximation of phase-flip hydrodynamics

M. M. BASKO

2021, 42(6):  871-884.  doi:10.1007/s10483-021-2734-6

摘要 ( 906 )   HTML ( 508)   PDF (572KB) ( 137 )

参考文献 | 相关文章 | 多维度评价

A finite-difference algorithm is proposed for numerical modeling of hydrodynamic flows with rarefaction shocks, in which the fluid undergoes a jump-like liquid-gas phase transition. This new type of flow discontinuity, unexplored so far in computational fluid dynamics, arises in the approximation of phase-flip (PF) hydrodynamics, where a highly dynamic fluid is allowed to reach the innermost limit of metastability at the spinodal, upon which an instantaneous relaxation to the full phase equilibrium (EQ) is assumed. A new element in the proposed method is artificial kinetics of the phase transition, represented by an artificial relaxation term in the energy equation for a "hidden" component of the internal energy, temporarily withdrawn from the fluid at the moment of the PF transition. When combined with an appropriate variant of artificial viscosity in the Lagrangian framework, the latter ensures convergence to exact discontinuous solutions, which is demonstrated with several test cases.

Heat transport of hybrid nanomaterial in an annulus with quadratic Boussinesq approximation

K. THRIVENI, B. MAHANTHESH

2021, 42(6):  885-900.  doi:10.1007/s10483-021-2739-6

摘要 ( 866 )   HTML ( 551)   PDF (6890KB) ( 161 )

参考文献 | 相关文章 | 多维度评价

The convective heat transfer of hybrid nanoliquids within a concentric annulus has wide engineering applications such as chemical industries, solar collectors, gas turbines, heat exchangers, nuclear reactors, and electronic component cooling due to their high heat transport rate. Hence, in this study, the characteristics of the heat transport mechanism in an annulus filled with the Ag-MgO/H₂O hybrid nanoliquid under the influence of quadratic thermal radiation and quadratic convection are analyzed. The nonuniform heat source/sink and induced magnetic field mechanisms are used to govern the basic equations concerning the transport of the composite nanoliquid. The dependency of the Nusselt number on the effective parameters (thermal radiation, nonlinear convection, and temperature-dependent heat source/sink parameter) is examined through sensitivity analyses based on the response surface methodology (RSM) and the face-centered central composite design (CCD). The heat transport of the composite nanoliquid for the spacerelated heat source/sink is observed to be higher than that for the temperature-related heat source/sink. The mechanisms of quadratic convection and quadratic thermal radiation are favorable for the momentum of the nanoliquid. The heat transport rate is more sensitive towards quadratic thermal radiation.

Shear-augmented solute dispersion during drug delivery for three-layer flow through microvessel under stress jump and momentum slip-Darcy model

G. BASHAGA, S. SHAW

2021, 42(6):  901-914.  doi:10.1007/s10483-021-2737-8

摘要 ( 901 )   HTML ( 748)   PDF (419KB) ( 65 )

参考文献 | 相关文章 | 多维度评价

Nanoparticle (drug particle) dispersion is an important phenomenon during nanodrug delivery in the bloodstream by using multifunctional carrier particles. The aim of this study is to understand the dispersion of drug particle (nanoparticle) transport during steady blood flow through a microvessel. A two-phase fluid model is considered to define blood flow through a microvessel. Plug and intermediate regions are defined by a non-Newtonian Herschel-Bulkley fluid model where the plug region appears due to the aggregation of red blood cells at the axis in the vessel. The peripheral (porous in nature) region is defined by the Newtonian fluids. The wall of the microvessel is considered to be permeable and characterized by the Darcy model. Stress-jump and velocity slip conditions are incorporated respectively at the interface of the intermediate and peripheral regions and at the inner surface of the microvessel. The effects of the rheological parameter, the pressure constant, the particle volume fraction, the stress jump constant, the slip constant, and the yield stress on the dispersion are analyzed and discussed. It is observed that the non-dimensional pressure gradient and the yield stress enhance the dispersion rate of the nanoparticle, while the opposite trends are observed for the velocity slip constant, the nanoparticle volume fraction, the rheological parameter, and the stress-jump constant.
