Hydrodynamical characterization of nanofluidic flow driven by forced convection via a four-sided lid-driven cavity

doi:10.1007/s10483-025-3271-6

Applied Mathematics and Mechanics (English Edition) ›› 2025, Vol. 46 ›› Issue (7): 1383-1402.doi: https://doi.org/10.1007/s10483-025-3271-6

收稿日期:2025-01-24 修回日期:2025-05-11 发布日期:2025-06-30

Hydrodynamical characterization of nanofluidic flow driven by forced convection via a four-sided lid-driven cavity

M. USMAN¹, M. HAMID²^,³^,^†(), W. A. KHAN⁴, R. U. HAQ⁵

^1.Institute of Mathematics, Poznan University of Technology, 61-138 Poznań, Poland
^2.School of Mathematics and Statistics, Nanjing University of Information Science and Technology, Nanjing 210044, China
^3.Department of Mathematics and Science Education, Faculty of Education, Harran University, Sanliurfa 63500, Türkiye
^4.Department of Pure and Applied Mathematics, Saveetha School of Engineering, Chennai 602105, Tamilnadu, India
^5.Department of Mathematics, School of Natural Sciences, National University of Sciences and Technology, Islamabad 44000, Pakistan

Received:2025-01-24 Revised:2025-05-11 Published:2025-06-30
Contact: M. HAMID E-mail:mhamid@pku.edu.cn
Supported by:
Project supported by the National Natural Science Foundation of China (No. 12250410244), the Jiangsu Funding Program for Excellent Postdoctoral Talent of China (No. 2023ZB884), the Foreign Expert Project funding of China (No. WGXZ2023017L), the Shuang-Chuang (SC) Doctor Program of Jiangsu Province, and the Longshan Scholar Program of Nanjing University of Information Science & Technology

摘要/Abstract

Abstract:

The unsteady magnetohydrodynamical (MHD) free convection flow of an incompressible, electrically conducting hybrid nanofluid within a vertical cylindrical geometry is investigated, incorporating the effects of thermal radiation, viscous dissipation, and internal heat generation. The system is subjected to a time-periodic boundary temperature condition. The Laplace and finite Hankel transforms are used to derive the exact solutions for the velocity and temperature distributions. The effects of various key physical parameters, including the Richardson number, the Eckert number, the radiation parameter, the heat source parameter, and the nanoparticle volume fraction, are considered. The numerical results reveal that increasing the volume fraction significantly enhances the thermal conductivity and temperature, while the magnetic field intensity and viscous dissipation strongly influence the fluid motion and heat transport. Additionally, the pulsating boundary conditions produce distinct oscillatory behaviors in both the velocity and temperature fields. These findings provide important insights into optimizing the heat transfer performance in cylindrical systems such as electronic cooling modules and energy storage devices operating under dynamic thermal conditions.

Key words: forced convection, lid-driven cavity, streamline, finite element method (FEM)

中图分类号:

O361

. [J]. Applied Mathematics and Mechanics (English Edition), 2025, 46(7): 1383-1402.

M. USMAN, M. HAMID, W. A. KHAN, R. U. HAQ. Hydrodynamical characterization of nanofluidic flow driven by forced convection via a four-sided lid-driven cavity[J]. Applied Mathematics and Mechanics (English Edition), 2025, 46(7): 1383-1402.

图/表 14

$D a$	$R e$	$ϕ$	$N u avg$
10^-4	250	0	0.988 88
10⁰	250	0	1.077 23
10³	250	0	1.090 07
$− 10$	10¹	0	0.268 35
$− 10$	10²	0	0.752 36
$− 10$	10³	0	2.047 59
$− 10$	500	0	1.614 83
$− 10$	500	0.1	1.548 78
$− 10$	500	0.2	1.320 99

参考文献 20

[6]	BHOPALAM, S. R., PERUMAL, D. A., and YADAV, A. K. Computational appraisal of fluid flow behavior in two-sided oscillating lid-driven cavities. International Journal of Mechanical Sciences, 196, 106303 (2021)
[7]	SOOMRO, F. A., HAMID, M., HUSSAIN, S. T., and HAQ, R. U. Constructional design and mixed convection heat transfer inside lid-driven semicircular cavity. European Physical Journal Plus, 137(7), 781 (2022)
[8]	KHAN, Z. H., KHAN, W. A., QASIM, M., ALHARBI, S. O., HAMID, M., and DU, M. Hybrid nanofluid flow around a triangular-shaped obstacle inside a split lid-driven trapezoidal cavity. European Physical Journal Special Topics, 231(13), 2749–2759 (2022)
[9]	AHMED, S. E., RAIZAH, Z., ARAFA, A. A. M., and HUSSEIN, S. A. FEM treatments for MHD highly mixed convection flow within partially heated double-lid driven odd-shaped enclosures using ternary composition nanofluids. International Communications in Heat and Mass Transfer, 145, 106854 (2023)
[10]	AHMED, S., CHEN, Z. M., XU, H., and ISHAQ, M. Mixed convection flow in a square lid-driven cavity subject to inclined magnetic field with highly accurate wavelet-homotopy solutions. Computers & Mathematics with Applications, 162, 33–51 (2024)
[11]	TAYEBI, T. and CHAMKHA, A. J. Magnetohydrodynamic natural convection heat transfer of hybrid nanofluid in a square enclosure in the presence of a wavy circular conductive cylinder. Journal of Thermal Science and Engineering Applications, 12(3), 031009 (2020)
[12]	HASHEMI-TILEHNOEE, M., DOGONCHI, A. S., SEYYEDI, S. M., CHAMKHA, A. J., and GANJI, D. D. Magnetohydrodynamic natural convection and entropy generation analyses inside a nanofluid-filled incinerator-shaped porous cavity with wavy heater block. Journal of Thermal Analysis and Calorimetry, 141(5), 2033–2045 (2020)
[13]	SEYYEDI, S. M., DOGONCHI, A. S., HASHEMI-TILEHNOEE, M., GANJI, D. D., and CHAMKHA, A. J. Second law analysis of magneto-natural convection in a nanofluid filled wavy-hexagonal porous enclosure. International Journal of Numerical Methods for Heat & Fluid Flow, 30(11), 4811–4836 (2020)
[14]	ALSABERY, A. I., TAYEBI, T., KADHIM, H. T., GHALAMBAZ, M., HASHIM, I., and CHAMKHA, A. J. Impact of two-phase hybrid nanofluid approach on mixed convection inside wavy lid-driven cavity having localized solid block. Journal of Advanced Research, 30, 63–74 (2021)
[15]	CHAMKHA, A. J., HUSSAIN, S. H., and ABD-AMER, Q. R. Mixed convection heat transfer of air inside a square vented cavity with a heated horizontal square cylinder. Numerical Heat Transfer, Part A: Applications, 59(1), 58–79 (2011)
[1]	ULLAH, M. Z., HUSSAIN, S. T., HAQ, R. U., ALZAHRANI, A. K., and MALLAWI, F. Thermal energy performance due to convection process of nanofluid in a porous medium due to split lid motion in a right triangular enclosure. Journal of Computational Design and Engineering, 9(3), 890–906 (2022)
[2]	BHATTACHARYA, M., BASAK, T., OZTOP, H. F., and VAROL, Y. Mixed convection and role of multiple solutions in lid-driven trapezoidal enclosures. International Journal of Heat and Mass Transfer, 63, 366–388 (2013)
[3]	THAKUR, M. S. H., ISLAM, M., UL KARIM, A., SAHA, S., and HASAN, M. N. Numerical study of laminar mixed convection in a Cu-water nanofluid filled lid-driven square cavity with an isothermally heated cylinder. AIP Conference Proceedings, 2121, 070017 (2019)
[4]	KHAN, Z. H., KHAN, W. A., HAMID, M., and LIU, H. T. Finite element analysis of hybrid nanofluid flow and heat transfer in a split lid-driven square cavity with Y-shaped obstacle. Physics of Fluids, 32(9), 093609 (2020)
[5]	ALSABERY, A. I., SHEREMET, M. A., SHEIKHOLESLAMI, M., CHAMKHA, A. J., and HASHIM, I. Magnetohydrodynamics energy transport inside a double lid-driven wavy-walled chamber: impacts of inner solid cylinder and two-phase nanoliquid approach. International Journal of Mechanical Sciences, 184, 105846 (2020)
[16]	ALSABERY, A. I., MOHEBBI, R., CHAMKHA, A. J., and HASHIM, I. Effect of local thermal non-equilibrium model on natural convection in a nanofluid-filled wavy-walled porous cavity containing inner solid cylinder. Chemical Engineering Science, 201, 247–263 (2019)
[17]	KHAN, Z. H., KHAN, W. A., SHEREMET, M. A., HAMID, M., and DU, M. Irreversibilities in natural convection inside a right-angled trapezoidal cavity with sinusoidal wall temperature. Physics of Fluids, 33(8), 083612 (2021)
[18]	HAMID, M., KHAN, Z. H., KHAN, W. A., and TIAN, Z. F. Natural convection inside a trapezoidal cavity under multidirectional magnetic impacts: finite element characterization. Physics of Fluids, 35(9), 093618 (2023)
[19]	HAMID, M., USMAN, M., KHAN, W. A., HAQ, R. U., and TIAN, Z. F. Natural convection and multidirectional magnetic field inside a square shaped cavity with sinusoidal temperature and heated/cold blocks. International Communications in Heat and Mass Transfer, 152, 107291 (2024)
[20]	HAMID, M., USMAN, M., KHAN, W. A., HAQ, R. U., and TIAN, Z. F. Characterizing natural convection and thermal behavior in a square cavity with curvilinear corners and central circular obstacles. Applied Thermal Engineering, 248, 123133 (2024)
