Applied Mathematics and Mechanics (English Edition) ›› 2024, Vol. 45 ›› Issue (1): 85-110.doi: https://doi.org/10.1007/s10483-024-3070-7
• Articles • Previous Articles Next Articles
Yong WANG1,2, Peili WANG1, Haodong MENG3, Liqun CHEN4,*(
)
Email Alert
RSSReceived:2023-05-25
Online:2024-01-01
Published:2023-12-26
Contact:
Liqun CHEN
E-mail:lqchen@shu.edu.cn
Supported by:2010 MSC Number:
Yong WANG, Peili WANG, Haodong MENG, Liqun CHEN. Dynamic performance and parameter optimization of a half-vehicle system coupled with an inerter-based X-structure nonlinear energy sink. Applied Mathematics and Mechanics (English Edition), 2024, 45(1): 85-110.
Fig. 1
Schematic diagram of the half-vehicle system coupled with IX-NES (color online)"
Table 1
Structural parameters of the half-vehicle system coupled with the IX-NES"
 |
Fig. 2
Geometric deformation of the X-structure (color online)"
Fig. 3
Comparison between the exact expression and Taylor series expansion of the nonlinear stiffness terms f1(zs, φ, zbf) and f2(zs, φ, zbr) (α = 45°, L = 0.15 m, kbf = kbr = 1 800 N·m–1, and φ = 0.01 rad) (color online)"
Fig. 4
Comparison between the analytical and numerical results of the dynamic response for the half-vehicle system coupled with the IX-NES under road harmonic excitation (A = 0.05 m, v = 20 m·s–1, L = 0.15 m, α = 45°, kbf = kbr = 1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 5
Schematic diagram of the half-vehicle system coupled with X-NES (color online)"
Fig. 6
Comparison of the dynamic performance indices for three half-vehicle systems with different vehicle speeds under road harmonic excitation (A = 0.05 m, L = 0.15 m, α = 45°, kbf = kbr = 1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 7
Dynamic performance indices of the half-vehicle system coupled with the IX-NES for different rod lengths under road harmonic excitation (A = 0.05 m, v = 20 m·s–1, α = 45°, kbf = kbr =1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 8
Dynamic performance indices of the half-vehicle system coupled with the IX-NES for different initial angles under road harmonic excitation (A = 0.05 m, v = 20 m·s–1, L = 0.15 m, kbf = kbr =1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 9
Dynamic performance indices of the half-vehicle system coupled with the IX-NES for different stiffness coefficients under road harmonic excitation (A = 0.05 m, v = 20 m·s–1, L = 0.15 m, α = 45°, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 10
Dynamic performance indices of the half-vehicle system coupled with the IX-NES for different damping coefficients under road harmonic excitation (A = 0.05 m, v = 20 m·s–1, L = 0.15 m, α = 45°, kbf = kbr =1 800 N·m–1, and bf = br = 100 kg) (color online)"
Fig. 11
Dynamic performance indices of the half-vehicle system coupled with the IX-NES for different inertances under road harmonic excitation (A = 0.05 m, v = 20 m·s–1, L = 0.15 m, α = 45°, kbf = kbr =1 800 N·m–1, and cbf = cbr = 1 200 N·s·m–1) (color online)"
Fig. 12
Comparison of the dynamic performance indices for three half-vehicle systems under road random excitation (v = 20 m·s–1, L = 0.15 m, α = 45°, kbf = kbr =1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, bf = br = 100 kg, and maf = mar = 100 kg) (color online)"
Table 2
RMS values of the dynamic performance indices for three half-vehicle systems under road random excitation (v = 20 m·s–1, L = 0.15 m, α = 45°, kbf = kbr =1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg)"
 |
Fig. 13
The RMS values of the dynamic performance indices of the half-vehicle system coupled with the IX-NES for different rod lengths under road random excitation (v = 20 m·s–1, α = 45°, kbf = kbr =1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 14
The RMS values of the dynamic performance indices of the half-vehicle system coupled with the IX-NES for different initial angles under road random excitation (v = 20 m·s–1, L = 0.15 m, kbf = kbr =1 800 N·m–1, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 15
The RMS values of the dynamic performance indices of the half-vehicle system coupled with the IX-NES for different stiffness coefficients under road random excitation (v = 20 m·s–1, L = 0.15 m, α = 45°, cbf = cbr = 1 200 N·s·m–1, and bf = br = 100 kg) (color online)"
Fig. 16
The RMS values of the dynamic performance indices of the half-vehicle system coupled with the IX-NES for different damping coefficients under road random excitation (v = 20 m·s–1, L = 0.15 m, α = 45°, kbf = kbr =1 800 N·m–1, and bf = br = 100 kg) (color online)"
Fig. 17
The RMS values of the dynamic performance indices of the half-vehicle system coupled with the IX-NES for different inertances under road random excitation (v = 20 m·s–1, L = 0.15 m, α = 45°, kbf = kbr =1 800 N·m–1, and cbf = cbr = 1 200 N·s·m–1) (color online)"
Table 3
The optimized structural parameters of the IX-NES"
 |
Fig. 18
Comparison of vehicle body vertical and pitching accelerations for three different half-vehicle systems under road random excitation (color online)"
Table 4
The RMS values of the dynamic performance indices for three different half-vehicle systems"
 |
